5.5.3 F Frame Circuit Breakers
Frame size Power & Voltage Type
F3 P450 380–500 V & P630-P710 525–690 V Merlin Gerin NPJF36120U31AABSCYP*
F4 P500-P630 380–500 V & P800 525–690 V Merlin Gerin NRJF36200U31AABSCYP*
F4 P710 380–500 V & P900-P1M0 525–690 V Merlin Gerin NRJF36200U31AABSCYP*
F4 P800 380–500 V Merlin Gerin NRJF36250U31AABSCYP*
* Drive SCCR rating maybe less than 100 kA when this option is added. See the drive label for SCCR rating.
5.5.4 F-Frame Line Power Contactors
Frame size Power & Voltage Type
F3 P450-P500 380–500 V & P630-P800 525–690 V Eaton XTCE650N22A*
F3 P560 380–500 V Eaton XTCE820N22A*
F3 P630380–500 V Eaton XTCEC14P22B*
F4 P900 525–690 V Eaton XTCE820N22A*
F4 P710-P800 380–500 V & P1M0 525–690 V Eaton XTCEC14P22B*
* Drive SCCR rating maybe less than 100 kA when this option is added. See the drive label for SCCR rating.
VLT
®
AQUA Drive Design Guide 5 How to Install
MG.20.N5.22 - VLT
®
is a registered Danfoss trademark 5-45
5

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
