Danfoss vlt aqua Design Guide

MCT 10
Set-up Software support Profibus DP-V1 via a master class 2 connection. This makes it possible to access on-line read/write parameters in an adjustable
frequency drive via the Profibus network. This will eliminate the need for an extra communication network.
Save Drive Settings:
1. Connect a PC to the unit via the USB com port.
2. Open MCT 10 Set-up Software
3. Choose “Read from drive”
4. Choose “Save as”
All parameters are now stored on the PC.
Load Drive Settings:
1. Connect a PC to the unit via the USB com port.
2. Open MCT 10 Set-up software
3. Choose “Open”– stored files will be shown.
4. Open the appropriate file
5. Choose “Write to drive”
All parameter settings are now transferred to the drive.
A separate manual for MCT 10 Set-up software is available.
The MCT 10 Set-up Software Modules
The following modules are included in the software package:
MCT 10 Set-up Software
Setting parameters
Copy to and from adjustable frequency drives
Documentation and print-out of parameter settings incl. diagrams
Ext. User Interface
Preventive Maintenance Schedule
Clock settings
Timed Action Programming
Smart Logic Controller Set-up
Cascade Control Config. Tool
Ordering number:
Please order your CD containing MCT 10 Set-up software using code number 130B1000.
The MCT 10 can also be downloaded from the Danfoss Internet:
WWW.DANFOSS.COM
, Business Area: Motion Controls.
MCT 31
The MCT 31 harmonic calculation PC tool enables easy estimation of the harmonic distortion in a given application. Both the harmonic distortion of Danfoss
adjustable frequency drives as well as non-Danfoss adjustable frequency drives with different additional harmonic reduction devices, such as Danfoss
AHF filters and 12-18-pulse rectifiers, can be calculated.
Ordering number:
Please order your CD containing the MCT 31 PC tool using code number 130B1031.
MCT 31 can also be downloaded from the Danfoss Internet:
WWW.DANFOSS.COM
, Business Area: Motion Controls.
VLT
®
AQUA Drive Design Guide 5 How to Install
MG.20.N5.22 - VLT
®
is a registered Danfoss trademark 5-53
5

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
