**Any minimum 500 V UL listed fuse with associated current rating may be used to meet UL requirements.
Supplementary fuses
Frame size Bussmann PN* Rating
D, E and F KTK-4 4 A, 600 V
Table 4.7: SMPS Fuse
Size/Type Bussmann PN* LittelFuse Rating
P160-P315, 380-480 V KTK-4 4 A, 600 V
P355-P710, 380-480 V KLK-15 15A, 600 V
Table 4.8: Fan Fuses
Size/Type Bussmann PN* Rating Alternative Fuses
P500-P710, 380-480 V 2.5-4.0 A LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 6A
P500-P710, 380-480 V 4.0-6.3 A LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 10 A
P500-P710, 380-480 V 6.3 - 10 A LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 15 A
P500-P710, 380-480 V 10 - 16 A LPJ-25 SP or SPI 25 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 25 A
Table 4.9: Manual Motor Controller Fuses
Frame size Bussmann PN* Rating Alternative Fuses
F LPJ-30 SP or SPI 30 A, 600 V Any listed Class J Dual Element, Time
Delay, 30 A
Table 4.10: 30 A Fuse Protected Terminal Fuse
Frame size Bussmann PN* Rating Alternative Fuses
D LP-CC-8/10 0.8A, 600V Any listed Class CC, 0.8A
E LP-CC-1 1/2 1.5A, 600V Any listed Class CC, 1.5A
F LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual Element, Time
Delay, 6 A
Table 4.11: Control Transformer Fuse
Frame size Bussmann PN* Rating
F GMC-800MA 800 mA, 250 V
Table 4.12: NAMUR Fuse
Frame size Bussmann PN* Rating Alternative Fuses
F LP-CC-6 6 A, 600 V Any listed Class CC, 6 A
Table 4.13: Safety Relay Coil Fuse with PILS Relay
4 How to Install
VLT AQUA Low Harmonic Drive Operating In-
structions
56 MG.20.T1.02 - VLT
®
is a registered Danfoss trademark
4
