[1833] Analog Out X42/7 [V] Shows the value of the signal applied to terminal X42/7 on the Analog I/O card.
[1834] Analog Out X42/9 [V] Shows the value of the signal applied to terminal X42/9 on the Analog I/O card.
[1835] Analog Out X42/11 [V] Shows the value of the signal applied to terminal X42/11 on the Analog I/O card.
[2117] Ext. 1 Reference [Unit] The value of the reference for extended Closed-loop Controller 1
[2118] Ext. 1 Feedback [Unit] The value of the feedback signal for extended Closed-loop Controller 1
[2119] Ext. 1 Output [%] The value of the output from extended Closed-loop Controller 1
[2137] Ext. 2 Reference [Unit] The value of the reference for extended Closed-loop Controller 2
[2138] Ext. 2 Feedback [Unit] The value of the feedback signal for extended Closed-loop Controller 2
[2139] Ext. 2 Output [%] The value of the output from extended Closed-loop Controller 2
[2157] Ext. 3 Reference [Unit] The value of the reference for extended Closed-loop Controller 3
[2158] Ext. 3 Feedback [Unit] The value of the feedback signal for extended Closed-loop Controller 3
[2159] Ext. Output [%] The value of the output from extended Closed-loop Controller 3
[2230] No-Flow Power The calculated No-Flow Power for the actual operating speed
[2580] Cascade Status Status for the operation of the cascade controller
[2581] Pump Status Status for the operation of each individual pump controlled by the cascade controller
[2791] Cascade Reference Reference output for use with follower drives.
[2792] % Of Total Capacity Readout parameter to show the system operating point as a % capacity of total system capacity.
[2793] Cascade Option Status Readout parameter to show the status of the cascade system.
NOTE!
Please consult the VLT
®
AQUA Drive Programming Guide, MG.20.OX.YY for detailed information.
0-21 Display Line 1.2 Small
Option: Function:
Select a variable for display in line 1, middle position.
[1662] * Analog input 53 The options are the same as those listed for par. 0-20
Display Line 1.1 Small
.
0-22 Display Line 1.3 Small
Option: Function:
Select a variable for display in line 1, right position.
[1614] * Motor Current The options are the same as those listed for par. 0-20
Display Line 1.1 Small
.
0-23 Display Line 2 Large
Option: Function:
Select a variable for display in line 2. The options are the same as those listed for par. 0-20
Display
Line 1.1 Small
.
[1615] * Frequency
0-24 Display Line 3 Large
Option: Function:
[1652] * Feedback [Unit] Select a variable for display in line 2. The options are the same as those listed for par. 0-20
Display
Line 1.1 Small
.
5 How to program the adjustable frequency
drive
VLT AQUA High Power Instruction Manual
5-12
MG.20.P3.22 - VLT
®
is a registered Danfoss trademark
5
