Mechanical dimensions, Frame size D
Frame Size D1 D2 D3 D4
150–175 HP [110–132 kW] at
400 V
(380–480 V)
60–250 HP [45–160 kW] at 690
V
(525–690 V)
250–350 HP [160–250 kW] at
400 V
(380–480 V)
300–550 HP [200–400 kW] at
690 V
(525–690 V)
150–175 HP
[110–132 kW]
at 400 V
(380–480 V)
60–250 HP
[45–160 kW]
at 690 V
(525–690 V)
250–350 HP
[160–250 kW]
at 400 V
(380–480 V)
300–550 HP
[200–400 kW]
at 690 V
(525–690 V)
IP
NEMA
21
Type 1
54
Type 12
21
Type 1
54
Type 12
00
Chassis
00
Chassis
Ship-
ping di-
men-
sions
Height
25.6 in [650
mm]
25.6 in [650 mm]
25.6 in [650
mm]
25.6 in [650 mm] 25.6 in [650 mm] 25.6 in [650 mm]
Width
68.1 in [1730
mm]
68.1 in [1730 mm]
68.1 in [1730
mm]
68.1 in [1730 mm] 48 in [1220 mm]
58.7 in [1490
mm]
Depth
22.4 in [570
mm]
22.4 in [570 mm]
22.4 in [570
mm]
22.4 in [570 mm] 22.4 in [570 mm] 22.4 in [570 mm]
Drive
dimen-
sions
Height
47.6 in [1209
mm]
47.6 in [1209 mm]
62.6 in [1589
mm]
62.6 in [1589 mm]
41.2 in [1046
mm]
52.2 in [1327
mm]
Width
16.5 in [420
mm]
16.5 in [420 mm]
16.5 in [420
mm]
16.5 in [420 mm] 16.1 in [408 mm] 16.1 in [408 mm]
Depth 15 in [380 mm] 15 in [380 mm] 15 in [380 mm] 15 in [380 mm] 14.8 in [375 mm] 14.8 in [375 mm]
Max weight 229 lb [104 kg] 229 lb [104 kg]
332.9 lbs [151
kg]
332.9 lbs [151 kg] 200 lbs [91 kg] 304 lbs [138 kg]
Mechanical dimensions, frame size E and F
Frame Size E1 E2 F1 F2 F3 F4
450–600 HP
[315–450 kW]
at 400 V
(380–480 V)
600–850 HP
[450–630 kW]
at 690 V
(525–690 V)
450–600 HP
[315–450 kW] at
400 V
(380–480 V)
1000–850 HP
[450–630 kW] at
690 V
(525–690 V)
675–950 HP
[500–710 kW]
at 400 V
(380–480 V)
950–1200 HP
[710–900 kW]
at 690 V
(525–690 V)
1075–1350 HP
[800–1000 kW]
at 400 V
(380–480 V)
1350–1600 HP
[1000–1200
kW] at 690 V
(525–690 V)
675–950 HP
[500–710 kW] at
400 V
(380–480 V)
950–1200 HP
[710–900 kW] at
690 V
(525–690 V)
1075–1350 HP
[800–1000 kW]
at 400 V
(380–480 V)
1350–1600 HP
[1000–1200 kW]
at 690 V
(525–690 V)
IP
NEMA
21, 54
Type 1/ Type 12
00
Chassis
21, 54
Type 1/ Type 12
21, 54
Type 1/ Type 12
21, 54
Type 1/ Type 12
21, 54
Type 1/ Type 12
Shipping di-
mensions
Height
33.1 in [840 mm] 32.7 in [831 mm] 91.5 in [2324 mm] 91.5 in [2324 mm] 91.5 in [2324 mm] 91.5 in [2324 mm]
Width 86.5 in [2197 mm] 67.1 in [1705 mm] 61.8 in [1569 mm] 77.2 in [1962 mm] 85 in [2159 mm]
100.1 in [2559
mm]
Depth 28 in [736 mm] 28 in [736 mm] 36.5 in [927 mm] 36.5 in [927 mm] 36.5 in [927 mm] 36.5 in [927 mm]
Drive dimen-
sions
Height 78.7 in [2000 mm] 60.9 in [1547 mm] 2204 2204 2204 2204
Width 23.6 in [600 mm] 23 in [585 mm] 1400 1800 2000 2400
Depth 19.5 in [494 mm] 19.6 in [498 mm] 606 606 606 606
Max
weight
690 lbs [313 kg] 610 [277 kg] 1004 1246 1299 1541
3 How to Install VLT AQUA High Power Instruction Manual
3-12 MG.20.P3.22 - VLT
®
is a registered Danfoss trademark
3
