Danfoss VLT AutomationDrive FC 302 Installation Guide

Table 2: Discharge Time, VLT® AutomationDrive FC 302
Voltage
[V]
Minimum waiting time (minutes)
4 7 15 20 30 40
200–240 0.25–3.7 kW
(0.34–5 hp)
– 5.5–37 kW (7.5–
50 hp)
– – –
380–500 0.25–7.5 kW
(0.34–10 hp)
– 11–75 kW (15–
100 hp)
90–200 kW (150–350
hp)
250–500 kW
(450–750 hp)
250–800 kW (450–
1350 hp) 315–500
(500–750 hp)
400 – – – 90–315 kW (125–450
hp)
– –
500 – – – 110–355 kW (150–
450 hp)
– –
525 – – – 55–315 kW (75–400
hp)
– –
525–600 0.75–7.5 kW (1–
10 hp)
– 11–75 kW (15–
100 hp)
– – –
525–690 – 1.5–7.5 kW
(2–10 hp)
11–75 kW (15–
100 hp)
37–315 kW (50–450
hp)
355–1200 kW
(450–1550 hp)
355–2000 kW
(450–2050 hp)
355–710 kW (400–
950 hp)
690 – – – 55–315 kW (75–400
hp)
– –
Table 3: Discharge Time, VLT® Decentral Drive FCD 302
Voltage [V] Minimum waiting time (minutes)
4 7 15
200–240 0.25–3.7 kW (0.34–5.0 hp) – 5.5–37 kW (7.5–50 hp)
380–500 0.25–7.5 kW (0.34–10 hp) – 11–75 kW (15–100 hp)
525–600 0.75–7.5 kW (1.0–10 hp) – 11–75 kW (15–100 hp)
525–690 – 1.5–7.5 kW (2.0–10 hp) 11–75 kW (15–100 hp)
W A R N I N G
UNINTENDED MOVEMENT
When external fores act on the motor, and unwanted movement, for example, caused by gravity, can cause a hazard. Failure to
take extra measures for fall protection can result in death r serious injury.
-
Equip the motor with fall protection, for example, extra mechanical brakes.
Safety
Installation Guide | VLT®Safety Option MCB 152
AN327351953089en-000101 / 130R0578
12 | Danfoss A/S © 2020.02

Danfoss VLT AutomationDrive FC 302 Specifications

General

Brand	Danfoss
Model	VLT AutomationDrive FC 302
Category	DC Drives
Language	English
