5.7 Commissioning Setup Examples
e30bc327.11
FC 302 1
FC 302 1
FC 302 1
FC 302 2
FC302 3
FC 302 2
MCT 10
RS485
MCB 15x
MCB 15x
MCB 15x
MCB 15x
MCB 15x MCB15x
MCT 10
1 2 3
2
1
1
RS485
USB
LCP
A
B
C
PROFIBUS
A Commission is done between VLT® Motion Control Tool MCT
10 and the drive.
C Safety options configured in a network using the MCT 10
software.
B Safety parameters are copied from 1 drive to another via the
LCP Copy function.
Illustration 24: Commissioning Setup Examples
