Danfoss VLT AutomationDrive FC 303 User Manual

Enclosure FC 300 Power Recommended
fuse size
Recommended
Max. fuse
Recommended circuit
breaker
Max. trip level
Size [kW] Moeller [A]
A2 0.75–4.0 gG-10 gG-25 PKZM0-25 25
A3 5.5–7.5 gG-10 (5.5)
gG-16 (7.5)
gG-32 PKZM0-25 25
B3 11–15 gG-25 (11)
gG-32 (15)
gG-63 PKZM4-50 50
B4 18.5–30 gG-40 (18.5)
gG-50 (22)
gG-63 (30)
gG-125 NZMB1-A100 100
C3 37–45 gG-63 (37)
gG-100 (45)
gG-150 NZMB2-A200 150
C4 55–75 aR-160 (55)
aR-200 (75)
aR-250 NZMB2-A250 250
A5 0.75–7.5 gG-10 (0.75–5.5)
gG-16 (7.5)
gG-32 PKZM0-25 25
B1 11–18 gG-25 (11)
gG-32 (15)
gG-40 (18.5)
gG-80 PKZM4-63 63
B2 22–30 gG-50 (22)
gG-63 (30)
gG-100 NZMB1-A100 100
C1 37–55 gG-63 (37)
gG-100 (45)
aR-160 (55)
gG-160 (37–45)
aR-250 (55)
NZMB2-A200 160
C2 75 aR-200 (75) aR-250 NZMB2-A250 250
Table 10.3 525–600V, Frame Sizes A, B, and C
Specifications
VLT
®
AutomationDrive Instruction
Manual
MG.33.AI.22 - VLT
®
is a registered Danfoss trademark 10-19
10
10
