Connect the 3-phase AC motor wiring to the dU/dt terminals U (T1), V (T2), and W (T3).
Tighten the terminals in accordance with the specifications shown in 10.11 Fastener Torque Ratings.
Example
Illustration 60: Connection Points for the dU/dt Filter to Motor
Factory-installed power cables from the drive mod-
ule
