1-93 Thermistor Source
Option: Function:
Select the input to which the thermistor (PTC sensor) should be connected. An analog input option [1] or [2]
cannot be selected if the analog input is already in use as a reference source (selected in par. 3-15
Reference
1 Source
, par. 3-16
Reference 2 Source
or par. 3-17
Reference 3 Source
).
When using MCB112, choice [0]
None
must always be selected.
[0]
*
None
[1] Analog input 53
[2] Analog input 54
[3] Digital input 18
[4] Digital input 19
[5] Digital input 32
[6] Digital input 33
This parameter cannot be adjusted while the motor is running.
NB!
Digital inputs should be set to “No operation” - see par. 5-1*
Digital Inputs
.
3.4. Main Menu - Brakes - Group 2
3.4.1. 2-0* DC-Brakes
Parameter group for configuring the DC brake and DC hold functions.
2-00 DC Hold Current/Preheat Current
Range: Function:
50 %
*
[0 - 100%]
Enter a value for holding current as a percentage of the rated motor current I
M,N
set in par. 1-24 Motor Current.
100% DC holding current corresponds to I
M,N
.
This parameter holds the motor function (holding torque) or pre-heats the motor.
This parameter is active if
DC hold
is selected in par. 1-80
Function at Stop
.
NB!
The maximum value depends on the rated motor current.
NB!
Avoid 100 % current for too long. It may damage the motor.
2-01 DC Brake Current
Range: Function:
50%
*
[0 - 100 %]
Enter a value for current as a percentage of the rated motor current I
M,N
, see par. 1-24
Motor Current
. 100% DC
braking current corresponds to I
M,N
.
DC brake current is applied on a stop command, when the speed is lower than the limit set in par. 2-03
DC Brake
Cut In Speed
; when the DC Brake Inverse function is active; or via the serial communication port. The braking
current is active during the time period set in par. 2-02
DC Braking Time
.
3. Parameter Description VLT
®
HVAC Drive Programming Guide
50
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
3
