NB!
The ramp time is automatically adjusted to avoid tripping of the frequency converter.
3.5. Main Menu - Reference/Ramps - Group 3
3.5.1. 3-0* Reference Limits
Parameters for setting the reference unit, limits and ranges.
Please see also par. 20-0*
Feedback
for information on settings in closed
loop.
3-02 Minimum Reference
Range: Function:
0.000
*
[-999999.999 to par. 3-03]
Enter the Minimum Reference. The Minimum Reference is the lowest value obtainable by summing all references.
The Minimum Reference value and unit matches the configuration choice made in par. 1-00 and par. 20-12
respectively.
NB!
This parameter is used in open loop only.
3-03 Maximum Reference
Option: Function:
[50.000]
*
Par. 3-02 to
+999999.999
Enter the Maximum Reference. The Maximum Reference is the highest value obtainable by summing all refer-
ences. The Maximum Reference value and unit matches the configuration choice made in par. 1-00 and par.
20-12 respectively.
NB!
This parameter is used in open loop only.
3-04 Reference Function
Option: Function:
[0]
*
Sum Sums both external and preset reference sources.
[1] External/Preset Use either the preset or the external reference source.
Shift between external and preset via a command on a digital input.
3.5.2. 3-1* References
Parameters for setting up the reference sources.
Select the preset reference(s).
Select Preset ref. bit 0 / 1 / 2
[16], [17] or [18] for the corresponding digital inputs in parameter group 5.1*
Digital
Inputs
.
3-10 Preset Reference
Array [8]
0.00%
*
[-100.00 - 100.00 %]
Enter up to eight different preset references (0-7) in this parameter, using array programming. The preset ref-
erence is stated as a percentage of the value Ref
MAX
(par. 3-03
Maximum Reference
) or as a percentage of the
other external references. If a Ref
MIN
different from 0 (Par. 3-02
Minimum Reference
) is programmed, the preset
reference is calculated as a percentage of the full reference range, i.e. on the basis of the difference between
VLT
®
HVAC Drive Programming Guide 3. Parameter Description
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
53
3
