3.11. Main Menu - CAN Fieldbus - Group 10
3.11.1. 10-** DeviceNet and CAN Fieldbus
Parameter group for DeviceNet CAN fieldbus parameters.
3.11.2. 10-0* Common Settings
Parameter group for configuring common settings for CAN fieldbus options.
10-00 CAN Protocol
Option: Function:
[1] *
DeviceNet View the active CAN protocol.
NB!
The options depend on installed option.
10-01 Baud Rate Select
Option: Function:
Select the fieldbus transmission speed. The selection must correspond to the transmission speed of the master
and the other fieldbus nodes.
[16] 10 Kbps
[17] 20 Kbps
[18] 50 Kbps
[19] 100 kbps
[20]
*
125 Kbps
[21] 250 Kbps
[22] 500 Kbps
[23] 800 Kbps
[24] 1000 Kbps
10-02 MAC ID
Range: Function:
63 * [0 - 127 ]
Selection of station address. Every station connected to the same DeviceNet network must have an unambiguous
address.
10-05 Readout Transmit Error Counter
Range: Function:
0 * [0 - 255]
View the number of CAN control transmission errors since the last power-up.
10-06 Readout Receive Error Counter
Option: Function:
[0] 0 - 255 View the number of CAN control receipt errors since the last power-up.
10-07 Readout Bus Off Counter
Range: Function:
0 * [0 - 255]
View the number of Bus Off events since the last power-up.
VLT
®
HVAC Drive Programming Guide 3. Parameter Description
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark 107
3
