Danfoss VLT FC 100 Series Programming Guide

3.11.3. 10-1* DeviceNet
Parameters specific to the DeviceNet fieldbus.
10-10 Process Data Type Selection
Option: Function:
Select the Instance (telegram) for data transmission. The Instances available are dependent upon the setting
of par. 8-10
Control Word Profile .
When par. 8-10 is set to [0]
FC profile , par. 10-10 options [0] and [1] are available.
When par. 8-10 is set to [5]
ODVA , par. 10-10 options [2] and [3] are available.
Instances 100/150 and 101/151 are Danfoss-specific. Instances 20/70 and 21/71 are ODVA-specific AC Drive
profiles.
For guidelines in telegram selection, please refer to the DeviceNet Operating Instructions.
Note that a change to this parameter will be executed immediately.
[0] Instance 100/150
[1] Instance 101/151
[2] Instance 20/70
[3] Instance 21/71
10-11 Process Data Config Write
Option: Function:
Select the process write data for I/O Assembly Instances 101/151. Elements [2] and [3] of this array can be
selected. Elements [0] and [1] of the array are fixed.
[0]
*
None
[3-02 ] Minimum reference
[3-03 ] Maximum reference
[3-41 ] Ramp 1 ramp up time
[3-42 ] Ramp 1 ramp down
time
[3-51 ] Ramp 2 ramp up time
[3-52 ] Ramp 2 ramp down
time
[3-80 ] Jog ramp time
[3-81 ] Quick stop ramp time
[4-11 ] Motor speed low limit
(RPM)
[4-13 ] Motor speed high limit
(RPM)
[4-16 ] Torque limit motor
mode
[4-17 ] Torque limit generator
mode
[5-90 ] Digital & Relay Bus
Control
[5-93 ] Pulse Out #27 Bus
Control
[5-95] Pulse Out #29 Bus
Control
[6-53 ] Terminal 42 Output
Bus Control
3. Parameter Description VLT
®
HVAC Drive Programming Guide
108 MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
3
