8-06 Reset Control Timeout
Option: Function:
This parameter is active only when the choice Hold set-up [0] has been selected in par. 8-05 End-of-Time-out
Function
.
[0]
*
Do not reset Retains the set-up specified in par. 8-04, [Select setup 1-4] following a control time-out.
[1] Do reset Returns the frequency converter to the original set-up following a control word time-out. When the value is set
to
Do reset [1], the frequency converter performs the reset and then immediately reverts to the Do not reset
[0] setting.
8-07 Diagnosis Trigger
Option: Function:
This parameter has no function for LonWorks.
[0]
*
Disable
[1] Trigger on alarms
[2] Trigger alarms/warn.
3.9.3. 8-1* Ctrl. Word Settings
Parameters for configuring the option control word profile.
8-10 Control Profile
Option: Function:
Select the interpretation of the control and status words corresponding to the installed fieldbus. Only the se-
lections valid for the fieldbus installed in slot A will be visible in the LCP display.
[0]
*
FC profile
8-13 Configurable Status Word STW
Option: Function:
This parameter enables configuration of bit 12 – 15 in the status word.
[0] No function
[1]
*
Profile default Function corresponds to the profile default selected in par. 8-10.
[2] Alarm 68 only Only set in case of an Alarm 68.
[3] Trip except Alarm 68 Set in case of a trip, except if the trip is executed by an Alarm 68.
[10] T18 DI status
[11] T19 DI status
[12] T27 DI status
[13] T29 DI status
[14] T33 DI status
[15] T33 DI status
[16] T37 DI status The bit indicates the status of terminal 37.
“0” indicates T37 is low (safe stop)
“1” indicates T37 is high (normal)
[21] Thermal warning
[30] Brake fault (IGBT)
[40] Out of ref range
[60] Comparator 0
[61] Comparator 1
VLT
®
HVAC Drive Programming Guide 3. Parameter Description
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark 91
3
