N O T I C E
Not all options are available in all power sizes.
Table 233: Option:
3 kHz true random PWM (white noise modulation).
5 kHz true random PWM (white noise modulation).
Select 2.0 kHz as the inverter switching frequency.
Select 3.0 kHz as the inverter switching frequency.
Select 4.0 kHz as the inverter switching frequency.
Select 5.0 kHz as the inverter switching frequency.
Select 6.0 kHz as the inverter switching frequency.
Select 8.0 kHz as the inverter switching frequency.
Select 10.0 kHz as the inverter switching frequency.
Select 12.0 kHz as the inverter switching frequency.
Select 16.0 kHz as the inverter switching frequency.
14-03 Overmodulation
Change during operation: False
Table 234: Option:
Select no overmodulation of the output voltage to avoid torque ripple on the motor shaft.
Select [1] On to obtain extra DC-link voltage and torque on the motor shaft.
14-07 Dead Time Compensation Level
Default value: Configuration dependent
Change during operation: False
Level of applied dead-time compensation in percentage. A high level (>90%) optimizes the dynamic motor response. A level 50–
90% is suitable for both motortorque- ripple minimization and motor dynamics. A 0 level turns off the dead-time compensation.
Table 235: Range:
Default value: Configuration dependent
14-08 Damping Gain Factor
Default value: Configuration dependent
Change during operation: True
Set the damping factor for DC-link voltage compensation. See parameter 14-51 DC-Link Voltage Compensation.
Table 236: Range:
Default value: Configuration dependent
