Table 291: Range:
Min: 0
Max: 2000
Default value: 0
15-97 Application Type
Default value: 0
Parameter type: Range
2-setup: 1 setup
Conversion index: 0
Data type: u_int32
Change during operation: True
This parameter contains data used by the MCT10 software tool.
Table 292: Range:
Min: 0
Max: 4294967295
Default value: 0
15-98 Drive Identification
Default value: 0
Parameter type: Range
2-setup: 1 setup
Conversion index: 0
Data type: VisibleString
Change during operation: False
This parameter contains data used by the MCT10 software tool.
Table 293: Range:
Min: 0
Max: 56
Default value: 0
4.13 Parameter Group 16-** Data Readouts
4.13.1 16-0* General Status
Parameters for reading the general status, for example, the calculated reference, the active control word, and status.
16-00 Control Word
Default value: 0
Parameter type: Range
2-setup: 1 setup
Conversion index: 0
Data type: u_int16
Change during operation: True
View the control word sent from the drive via the serial communication port in hex code.
Table 294: Control Word
Bit
Bit=0
Bit=1
00
Preset reference option lsb
–
01
Preset reference option 2
nd
bit of preset references
–
02
DC brake
Ramp
03
Coasting
Enable
04
Quick stop
Ramp
05
Freeze output
Ramp
06
Ramp stop
Start
07
No function
Reset
08
No function
Jog
09
Ramp 1
Ramp 2
10
Data not valid
Valid
AU363928304090en-000101 / 130R0982144 | Danfoss A/S © 2021.07
Parameters
VLT® Flow Drive FC 111
Programming Guide
