Danfoss VLT Flow Drive FC 111 User Manual

Bit
Bit=0
Bit=1
11
Relay_A not active
Relay_A active
12
Relay_B not active
Relay_B active
13
Choice of setup lsb
–
14
No function
No function
15
No function
Reversing
Table 295: Range:
Min: 0
Max: 65535
Default value: 0
16-01 Reference [Unit]
Default value: 0 ReferenceFeedbackUnit
Parameter type: Range
2-setup: 1 setup
Conversion index: -3
Data type: int32
Change during operation: True
View the present reference value applied on impulse or analog basis in the unit resulting from the configuration selected in parame-
ter 1-00 Configuration Mode (Hz).
Table 296: Range:
Min: -4999
Max: -4999 ReferenceFeedbackUnit
Default value: 0 ReferenceFeedbackUnit
16-02 Reference [%]
Default value: 0.0%
Parameter type: Range
2-setup: 1 setup
Conversion index: -1
Data type: int16
Change during operation: True
View the total reference. The total reference is the sum of digital, analog, preset, bus, and freeze references.
Table 297: Range:
Min: -200.0%
Max: 200.0%
Default value: 0.0%
16-03 Status Word
Default value: 0
Parameter type: Range
2-setup: 1 setup
Conversion index: 0
Data type: u_int16
Change during operation: True
View the status word sent from the drive via the serial communication port in hex code.
Table 298: Control Word
Bit
Bit=0
Bit=1
00
Control not ready
Ready
01
VLT not ready
Ready
02
Coasting
Enable
03
No fault
Trip
04
No warning
Warning
05
Reserved
–
06
No trip lock
Trip lock
AU363928304090en-000101 / 130R0982 | 145Danfoss A/S © 2021.07
Parameters
VLT® Flow Drive FC 111
Programming Guide
