Table 147: Range:
5-53 Term. 29 High Ref./Feedb. Value
Default value: Configuration dependent
Change during operation: True
Enter the reference or feedback value (in for example, RPM, Hz, bar) that corresponds to the pulse frequency set in parameter 5-51
Term. 29 High Frequency.
Table 148: Range:
Default value: Configuration dependent
4.7.6 5-8* I/O Options
5-80 AHF Cap Reconnect Delay
Change during operation: True
Delay time between 2 consecutive AHF capacitor connections. Timer starts once the AHF capacitor disconnect and connects back
once the delay expires and the drive power is above 20% and below 30% of nominal power.
Table 149: Range:
4.7.7 5-9* Bus Controlled
This parameter group selects digital and relay outputs via a fieldbus setting.
5-90 Digital & Relay Bus Control
Change during operation: True
This parameter holds the state of the buscontrolled digital outputs and relays. A logical 1 indicates that the output is high or active.
A logical 0 indicates that the output is low or inactive.
Table 150: Range:
4.8 Parameter Group 6-** Analog In/Out
Parameter group for setting up the analog I/O configuration and the digital output.
The drive provides 2 analog inputs:
Terminal 53.
Terminal 54.
The analog inputs can be freely allocated to either voltage (0–10 V) or current input (0/4–20 mA).
4.8.1 6-0* Analog I/O Mode
6-00 Live Zero Timeout Time
Change during operation: True
Enter the timeout time.
