Table 332: Bit Definitions
Bit 0
Digital output terminal 27
Bit 1
Digital output terminal 29
Bit 2
Digital output terminal 42
Bit 3
Digital output terminal 45
Bit 4–15
Unused
Table 333: Range:
Min: 0
Max: 15
Default value: 0
16-67 Pulse Input #29 [Hz]
Default value: 0
Parameter type: Range
2-setup: All setups
Conversion index: 0
Data type: int32
Change during operation: False
View the actual value of the frequency applied at terminal 29 as a pulse input.
Table 334: Range:
Min: 0
Max: 130000
Default value: 0
16-71 Relay output
Default value: 0
Parameter type: Range
2-setup: 1 setup
Conversion index: 0
Data type: u_int16
Change during operation: True
View the setting of the relay.
Table 335: Bit Definitions
Bit 0–2
Unused
Bit 3
Relay 02
Bit 4
Relay 01
Bit 5–15
Unused
Table 336: Range:
Min: 0
Max: 31
Default value: 0
16-72 Counter A
Default value: 0
Parameter type: Range
2-setup: 1 setup
Conversion index: 0
Data type: int16
Change during operation: True
View the present value of counter A. Counters are useful as comparator operands, see parameter 13-10 Comparator Operand. The
value can be reset or changed either via digital inputs (parameter group 5-1* Digital Inputs) or by using an SLC action (parameter
13-52 SL Controller Action).
Table 337: Range:
Min: -32768
Max: 32767
Default value: 0
AU363928304090en-000101 / 130R0982 | 153Danfoss A/S © 2021.07
Parameters
VLT® Flow Drive FC 111
Programming Guide
