Danfoss VLT Flow Drive FC 111 User Manual

No.
Description
Warning
Alarm
Trip Lock
Parameter Reference
30
Motor phase U missing
–
(X)
(X)
Parameter 4-58 Missing Motor Phase Func-
tion
31
Motor phase V missing
–
(X)
(X)
Parameter 4-58 Missing Motor Phase Func-
tion
32
Motor phase W missing
–
(X)
(X)
Parameter 4-58 Missing Motor Phase Func-
tion
38
Internal fault
–
X
X
–
44
Ground fault 2
–
X
X
–
46
Gate drive voltage fault
–
X
X
–
47
24 V supply low
–
X
X
–
51
AMA check U
nom
and I
nom
–
X
–
–
52
AMA low I
nom
–
X
–
–
53
AMA motor too large
–
X
–
–
54
AMA motor too small
–
X
–
–
55
AMA parameter out of range
–
X
–
–
56
AMA interrupted
–
X
–
–
57
AMA time-out
–
X
–
–
58
AMA internal fault
X
X
–
–
59
Current limit
X
–
–
–
60
External interlock
–
X
–
–
66
Heat sink temperature low
X
–
–
–
69
Power card temperature
X
X
X
–
70
Illegal FC Configuration
–
X
X
–
79
Illegal PS config
X
X
–
–
80
Drive initialised to default value
–
X
–
–
92
No-Flow
(X)
(X)
–
Parameter 22-23 No-Flow Function
93
Dry pump
X
X
–
Parameter 22-26 Dry Pump Function
94
End of curve
X
X
–
Parameter 22-50 End of Curve Function
95
Broken belt
X
X
–
Parameter group 22-6* Broken Belt Detec-
tion
99
Locked rotor
–
X
X
–
101
Flow/pressure Info Missing
–
–
–
–
126
Motor rotating
–
X
–
–
127
Back EMF too high
X
–
–
–
AU363928304090en-000101 / 130R0982192 | Danfoss A/S © 2021.07
Troubleshooting
VLT® Flow Drive FC 111
Programming Guide
