[168]
Drive in hand mode
The output is high when the drive is in hand-on mode (as indicated by the LED light above
[Hand On]).
[169]
Drive in auto mode
The output is high when the drive is in auto-on mode (as indicated by the LED light above [Auto
On]).
[188]
AHF Capacitor Con-
nect
Connect or disconnect AHF capacitor.
[190]
No-Flow
A no-flow condition has been detected. See parameter group 22-2* No-Flow Detection.
[191]
Dry Pump
A dry-pump condition has been detected. Enable the function in parameter 22-26 Dry Pump
Function.
[192]
End Of Curve
An end-of-curve condition has been detected. Enable the function in parameter 22-50 End of
Curve Function.
[193]
Sleep Mode
The drive/system has entered sleep mode. See parameter group 22-4* Sleep Mode.
[194]
Broken Belt Function
A broken-belt condition has been detected. Enable the function in parameter 22-60 Broken Belt
Function.
[196]
Fire Mode
The drive is operating in fire mode. See parameter group 24-0* Fire Mode.
[198]
Drive Bypass
To be used as a signal for activating an external electromechanical bypass, switching the motor
directly on line. See parameter group 24-1* Drive Bypass.
[200]
Full capacity
The drive enters full capacity mode.
[201]
Pump 1 running
Pump 1 is running.
[202]
Pump 2 running
Pump 2 is running.
[203]
Pump 3 running
Pump 3 is running.
[204]
Pump 4 running
Pump 4 is running.
[205]
Pump 5 running
Pump 5 is running.
[211]
Cascade Pump 1
Cascade pump 1 is running.
[212]
Cascade Pump 2
Cascade pump 2 is running.
[213]
Cascade Pump 3
Cascade pump 3 is running.
[214]
Cascade Pump 4
Cascade pump 4 is running.
[215]
Cascade Pump 5
Cascade pump 5 is running.
5-34 On Delay, Digital Output
Default value: 0.01 s
Parameter type: Range
2-setup: All setups
Conversion index: -2
Data type: u_int16
Change during operation: True
Enter the delay time before the digital output is switched on. The digital output (terminal 42/45) condition must not be interrupted
during the delay time.
Table 140: Range:
Min: 0 s
Max: 600 s
Default value: 0.01 s
AU363928304090en-000101 / 130R0982 | 85Danfoss A/S © 2021.07
Parameters
VLT® Flow Drive FC 111
Programming Guide
