6-11 Terminal 53 High Voltage
Default value: 10 V
Parameter type: Range
2-setup: All setups
Conversion index: -2
Data type: u_int16
Change during operation: True
Enter the voltage (V) that corresponds to the high reference value (set in parameter 6-15 Terminal 53 High Ref./Feedb. Value).
Table 155: Range:
Min: 0 V
Max: 10 V
Default value: 10 V
6-12 Terminal 53 Low Current
Default value: 4 mA
Parameter type: Range
2-setup: All setups
Conversion index: -2
Data type: u_int16
Change during operation: True
Enter the low current value. This reference signal corresponds to the low reference/feedback value that is set in parameter 6-14 Ter-
minal 53 Low Ref./Feedb. Value. To activate parameter 6-01 Live Zero Timeout Function, set the value to >2 mA.
Table 156: Range:
Min: 0 mA
Max: 20 mA
Default value: 4 mA
6-13 Terminal 53 High Current
Default value: 20 mA
Parameter type: Range
2-setup: All setups
Conversion index: -2
Data type: u_int16
Change during operation: True
Enter the high current value corresponding to the high reference/feedback set in parameter 6-15 Terminal 53 High Ref./Feedb. Value.
Table 157: Range:
Min: 0 mA
Max: 20 mA
Default value: 20 mA
6-14 Terminal 53 Low Ref./Feedb. Value
Default value: 0
Parameter type: Range
2-setup: All setups
Conversion index: -3
Data type: int32
Change during operation: True
Enter the reference or feedback value that corresponds to the voltage or current set in parameter 6-10 Terminal 53 Low Voltage to
parameter 6-12 Terminal 53 Low Current.
Table 158: Range:
Min: -4999
Max: 4999
Default value: 0
6-15 Terminal 53 High Ref./Feedb. Value
Default value: Configuration dependent
Parameter type: Range
2-setup: All setups
Conversion index: -3
Data type: int32
Change during operation: True
Enter the reference or feedback value that corresponds to the voltage or current set in parameter 6-11 Terminal 53 High Voltage to
parameter 6-13 Terminal 53 High Current.
Table 159: Range:
Min: -4999
Max: 4999
Default value: Configuration dependent
AU363928304090en-000101 / 130R0982 | 93Danfoss A/S © 2021.07
Parameters
VLT® Flow Drive FC 111
Programming Guide
