Custom Readout (Value)
P 16-09
Custom Readout
Unit P 0-30
Max value
P 0-32
Min value
Liniar
units only
P 0-31
Motor Speed
130BB779.10
Motor Speed
High limit
P 4-14 (Hz)
Linear Unit (e.g. Speed and ow)
Quadratic Unit (Pressure)
Cubic Unit (Power)
Illustration 3.1 Custom Readout
The relation depends on the type of unit selected in
parameter 0-30 Custom Readout Unit:
Unit type Speed relation
Dimensionless
Linear
Speed
Flow, volume
Flow, mass
Velocity
Length
Temperature
Pressure Quadratic
Power Cubic
Table 3.1 Speed Relation
0-30 Custom Readout Unit
Option: Function:
Program a value to be shown in the
display of the LCP. The value has a linear,
squared, or cubed relation to speed. This
relation depends on the unit selected (see
Table 3.1). The actual calculated value can
be read in parameter 16-09 Custom
Readout.
[0] None
[1] * %
[5] PPM
[10] l/Min
[11] RPM
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m3/s
[24] m3/min
[25] m3/h
0-30 Custom Readout Unit
Option: Function:
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] Degree Celsius
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m Wg
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[127] ft3/h
[140] ft/s
[141] ft/min
[160] Degree Fahr
[170] psi
[171] lb/in2
[172] in WG
[173] ft WG
[180] hp
0-31 Custom Readout Min Value
Range: Function:
0 CustomRea-
doutUnit*
[ 0 -
999999.99
CustomRea-
doutUnit]
This parameter sets the
minimum value of the custom-
dened readout (occurs at 0
speed). It is only possible to
select a value dierent from 0
when selecting a linear unit in
parameter 0-30 Custom Readout
Unit. For quadratic and cubic
units, the minimum value is 0.
0-32 Custom Readout Max Value
Range: Function:
100 Custom-
ReadoutUnit*
[ 0.0 -
999999.99
CustomRea-
doutUnit]
This parameter sets the
maximum value to be shown
when the speed of the motor
has reached the set value for
parameter 4-14 Motor Speed
High Limit [Hz].
Parameters
VLT
®
HVAC Basic Drive FC 101
28 Danfoss A/S © 04/2018 All rights reserved. MG18B502
33
