Danfoss VLT HVAC Drive FC 102 - Page 102

0.0
244 (9.6)
44 (1.8)
939 (37.0)
1031 (40.6)
0.0
135 (5.3)
0.0
130BF587.10
171 (6.7)
119 (4.7)
128 (5.0)
76 (3.0)
1
2
1 Mains terminals 2 Ground bar
Illustration 8.36 Terminal Dimensions for F3–F4 Options Cabinet, Side View
