4.4 Overview of Enclosures, 525–690 V
Enclosure size E1 E2
Power rating
1)
Output at 690 V (kW) 450–630 450–630
Output at 575 V (hp) 450–650 450–650
Front-end conguration
6-pulse S S
12-pulse – –
Protection rating
IP IP21/54 IP00
UL type Type 1/12 Chassis
Hardware options
2)
Stainless steel back channel – O
Mains shielding O –
Space heater and thermostat – –
Cabinet light with power outlet – –
RFI lter (Class A1) O O
NAMUR terminals – –
Insulation resistance monitor (IRM) – –
Residual current monitor (RCM) – –
Brake chopper (IGBTs) O O
Safe Torque O S S
Regen terminals O O
Common motor terminals – –
Emergency stop with Pilz safety relay – –
Safe Torque O with Pilz safety relay – –
No LCP – –
Graphical LCP S S
Numerical LCP O O
Fuses O O
Load share terminals O O
Fuses + load share terminals O O
Disconnect O O
Circuit breakers – –
Contactors – –
Manual motor starters – –
30 A, fuse-protected terminals – –
24 V DC supply (SMPS, 5 A) O O
External temperature monitoring – –
Dimensions
Height, mm (in) 2000 (78.8) 1547 (60.9)
Width, mm (in) 600 (23.6) 585 (23.0)
Depth, mm (in) 494 (19.4) 498 (19.5)
Weight, kg (lb) 263–313 (580–690) 221–277 (487–611)
Table 4.6 E1–E2 Drives, 525–690 V
1) All power ratings are taken at normal overload. Output is measured at 690 V (kW) and 575 V (hp).
2) S = standard, O = optional, and a dash indicates that the option is unavailable.
