Danfoss VLT HVAC Drive FC 102 - Page 76

130BF600.10
0.0
51 (2.0)
226 (8.9)
266 (10.5) 441 (17.4)
0.0
28 (1.1)
167 (6.6)
195 (7.7)
371 (14.6)
1
1 Mains terminals – –
Illustration 8.9 Terminal Dimensions for E1 with Disconnect (380–480/500 V Models: P355–P400), Side View
