Danfoss VLT HVAC Drive User Manual

Par. No. # Parameter description Default value 4 set-up Change during
operation
Conver-
sion index
Type
0-0* Basic Settings 0-01 Language [0] English 1 set-up TRUE - Uint8 0-02 Motor Speed Unit [0] RPM 2 set-ups FALSE - Uint8
0-03 Regional Settings [0] International 2 set-ups FALSE - Uint8
0-04 Operating State at Power-up [0] Resume All set-ups TRUE - Uint8
0-05
Local Mode Unit [0] As Motor Speed Unit 2 set-ups FALSE - Uint8
0-1* Set-up Operations 0-10 Active Set-up [1] Set-up 1 1 set-up TRUE - Uint8 0-11 Programming Set-up [9] Active Set-up All set-ups TRUE - Uint8
0-12 This Set-up Linked to [0] Not linked All set-ups FALSE - Uint8
0-13 Readout: Linked Set-ups 0 N/A All set-ups FALSE 0 Uint16
0-14
Readout: Prog. Set-ups/Channel 0 N/A All set-ups TRUE 0 Int32
0-2* LCP Display 0-20 Display Line 1.1 Small 1602 All set-ups TRUE - Uint16 0-21 Display Line 1.2 Small 1614 All set-ups TRUE - Uint16
0-22 Display Line 1.3 Small 1610 All set-ups TRUE - Uint16
0-23 Display Line 2 Large 1613 All set-ups TRUE - Uint16
0-24 Display Line 3 Large 1502 All set-ups TRUE - Uint16
0-25 My Personal Menu ExpressionLimit 1 set-up TRUE 0 Uint16 0-3* LCP Custom Readout 0-30 Custom Readout Unit [1] % All set-ups TRUE - Uint8 0-31 Custom Readout Min Value ExpressionLimit All set-ups TRUE -2 Int32 0-32 Custom Readout Max Value 100.00 CustomReadoutUnit All set-ups TRUE -2 Int32
0-37 Display Text 1 0 N/A 1 set-up TRUE 0 VisStr[25]
0-38 Display Text 2 0 N/A 1 set-up TRUE 0 VisStr[25]
0-39
Display Text 3 0 N/A 1 set-up TRUE 0 VisStr[25]
0-4* LCP Keypad 0-40 [Hand on] Key on LCP [1] Enabled All set-ups TRUE - Uint8 0-41 [Off] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-42 [Auto on] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-43 [Reset] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-44 [Off/Reset] Key on LCP [1] Enabled All set-ups TRUE - Uint8
0-45 [Drive Bypass] Key on LCP [1] Enabled All set-ups TRUE - Uint8 0-5* Copy/Save 0-50 LCP Copy [0] No copy All set-ups FALSE - Uint8 0-51 Set-up Copy [0] No copy All set-ups FALSE - Uint8
6.2.1. 0-** Operation and Display
6. How to program the adjustable frequency
drive
VLT
®
HVAC Drive Instruction Manual
100 MG.11.A4.22 - VLT
®
is a registered Danfoss trademark
6

Danfoss VLT HVAC Drive Specifications

General

Type	VLT HVAC Drive
STO (Safe Torque Off)	Yes
Enclosure	IP20
Output Frequency	0-500 Hz
Brake Chopper	Built-in (depending on frame size)
EMC Filter	Built-in (depending on frame size)
Communication	Ethernet
Power Range	0.37 kW to 630 kW
Input Voltage	200-240V, 380-480V, 525-600V
Protection Features	Overload, Overvoltage, Undervoltage, Short Circuit, Ground Fault
Ambient Temperature	-10°C to +50°C (with derating above +40°C)
Storage Temperature	-25°C to +70°C
Relative Humidity	5-95% (non-condensing)
Cooling Method	Air-cooled
