Par. No. # Parameter description Default value 4 set-up FC 302
only
Change during operation Conver-
sion index
Type
10-0* Common Settings
10-00 CAN Protocol null 2 set-ups FALSE - Uint8
10-01 Baud Rate Select null 2 set-ups TRUE - Uint8
10-02 MAC ID ExpressionLimit 2 set-ups TRUE 0 Uint8
10-05 Readout Transmit Error Counter 0 N/A All set-ups TRUE 0 Uint8
10-06 Readout Receive Error Counter 0 N/A All set-ups TRUE 0 Uint8
10-07 Readout Bus Off Counter 0 N/A All set-ups TRUE 0 Uint8
10-1* DeviceNet
10-10 Process Data Type Selection null All set-ups TRUE - Uint8
10-11 Process Data Config Write ExpressionLimit 2 set-ups TRUE - Uint16
10-12 Process Data Config Read ExpressionLimit 2 set-ups TRUE - Uint16
10-13 Warning Parameter 0 N/A All set-ups TRUE 0 Uint16
10-14 Net Reference [0] Off 2 set-ups TRUE - Uint8
10-15
Net Control [0] Off 2 set-ups TRUE - Uint8
10-2* COS Filters
10-20 COS Filter 1 0 N/A All set-ups FALSE 0 Uint16
10-21 COS Filter 2 0 N/A All set-ups FALSE 0 Uint16
10-22 COS Filter 3 0 N/A All set-ups FALSE 0 Uint16
10-23 COS Filter 4 0 N/A All set-ups FALSE 0 Uint16
10-3* Parameter Access
10-30 Array Index 0 N/A 2 set-ups TRUE 0 Uint8
10-31 Store Data Values [0] Off All set-ups TRUE - Uint8
10-32 DeviceNet Revision ExpressionLimit All set-ups TRUE 0 Uint16
10-33 Store Always [0] Off 1 set-up TRUE - Uint8
10-34 DeviceNet Product Code 120 N/A 1 set-up TRUE 0 Uint16
10-39 DeviceNet F Parameters 0 N/A All set-ups TRUE 0 Uint32
6.2.10. 10-**CAN Ser. Com. Bus
6. How to program the adjustable frequency
drive
VLT
®
HVAC Drive Instruction Manual
112
MG.11.A4.22 - VLT
®
is a registered Danfoss trademark
6
