Danfoss VLT HVAC Drive User Manual

8. Specifications
8.1. Specifications
8.1.1. Line Supply 3 x 200-240 V AC
Normal overload 110% for 1 minute
IP 20 A2 A2 A2 A3 A3
IP 21 A2 A2 A2 A3 A3
IP 55 A5 A5 A5 A5 A5
IP 66
A5 A5 A5 A5 A5
Line supply 200-240 V AC
Adjustable frequency drive
Typical Shaft Output [kW]
P1K1
1.1
P1K5
1.5
P2K2
2.2
P3K0
3
P3K7
3.7
Typical Shaft Output [HP] at 208 V 1.5 2.0 2.9 4.0 4.9
Output current
Continuous
(3 x 200-240 V) [A]
6.6 7.5 10.6 12.5 16.7
Intermittent
(3 x 200-240 V) [A]
7.3 8.3 11.7 13.8 18.4
Continuous
kVA (208 V AC) [kVA]
2.38 2.70 3.82 4.50 6.00
Max. cable size:
(line, motor, brake)
[mm
2
/AWG]
2)
4/10
Max. input current
Continuous
(3 x 200-240 V) [A]
5.9 6.8 9.5 11.3 15.0
Intermittent
(3 x 200-240 V) [A]
6.5 7.5 10.5 12.4 16.5
Max. pre-fuses
1)
[A]
20 20 20 32 32
Environment
Estimated power loss
at rated max. load [W]
4)
63 82 116 155 185
Weight enclosure IP 20 [kg] 4.9 4.9 4.9 6.6 6.6
Weight enclosure IP 21 [kg] 5.5 5.5 5.5 7.5 7.5
Weight enclosure IP 55 [kg] 13.5 13.5 13.5 13.5 13.5
Weight enclosure IP 66 [kg] 13.5 13.5 13.5 13.5 13.5
Efficiency
3)
0.96 0.96 0.96 0.96 0.96
VLT
®
HVAC Drive Instruction Manual 8. Specifications
MG.11.A4.22 - VLT
®
is a registered Danfoss trademark 139
8

Danfoss VLT HVAC Drive Specifications

General

Type	VLT HVAC Drive
STO (Safe Torque Off)	Yes
Enclosure	IP20
Output Frequency	0-500 Hz
Brake Chopper	Built-in (depending on frame size)
EMC Filter	Built-in (depending on frame size)
Communication	Ethernet
Power Range	0.37 kW to 630 kW
Input Voltage	200-240V, 380-480V, 525-600V
Protection Features	Overload, Overvoltage, Undervoltage, Short Circuit, Ground Fault
Ambient Temperature	-10°C to +50°C (with derating above +40°C)
Storage Temperature	-25°C to +70°C
Relative Humidity	5-95% (non-condensing)
Cooling Method	Air-cooled
