Danfoss VLT HVAC Drive User Manual

Par. No. # Parameter description Default value 4 set-up Change during
operation
Conver-
sion index
Type
13-0* SLC Settings 13-00 SL Controller Mode null 2 set-ups TRUE - Uint8 13-01 Start Event null 2 set-ups TRUE - Uint8
13-02 Stop Event null 2 set-ups TRUE - Uint8
13-03 Reset SLC [0] Do not reset SLC All set-ups TRUE - Uint8 13-1* Comparators 13-10 Comparator Operand null 2 set-ups TRUE - Uint8 13-11 Comparator Operator null 2 set-ups TRUE - Uint8 13-12 Comparator Value ExpressionLimit 2 set-ups TRUE -3 Int32 13-2* Timers 13-20 SL Controller Timer ExpressionLimit 1 set-up TRUE -3 TimD 13-4* Logic Rules 13-40 Logic Rule Boolean 1 null 2 set-ups TRUE - Uint8 13-41 Logic Rule Operator 1 null 2 set-ups TRUE - Uint8 13-42 Logic Rule Boolean 2 null 2 set-ups TRUE - Uint8
13-43 Logic Rule Operator 2 null 2 set-ups TRUE - Uint8
13-44 Logic Rule Boolean 3 null 2 set-ups TRUE - Uint8 13-5* States 13-51 SL Controller Event null 2 set-ups TRUE - Uint8 13-52 SL Controller Action null 2 set-ups TRUE - Uint8
6.2.12. 13-** Smart Logic
6. How to program the adjustable frequency
drive
VLT
®
HVAC Drive Instruction Manual
114 MG.11.A4.22 - VLT
®
is a registered Danfoss trademark
6

Danfoss VLT HVAC Drive Specifications

General

Type	VLT HVAC Drive
STO (Safe Torque Off)	Yes
Enclosure	IP20
Output Frequency	0-500 Hz
Brake Chopper	Built-in (depending on frame size)
EMC Filter	Built-in (depending on frame size)
Communication	Ethernet
Power Range	0.37 kW to 630 kW
Input Voltage	200-240V, 380-480V, 525-600V
Protection Features	Overload, Overvoltage, Undervoltage, Short Circuit, Ground Fault
Ambient Temperature	-10°C to +50°C (with derating above +40°C)
Storage Temperature	-25°C to +70°C
Relative Humidity	5-95% (non-condensing)
Cooling Method	Air-cooled
