Danfoss VLT Midi Drive FC 280 Programming Guide

Fault Reason for details about the fault.
This option is only eective when
parameter 37-00 Application Mode is set to
[2] Position Control.
[173] Position Mech
Brake
Selects mechanical control for positioning.
This option is only eective when
parameter 37-00 Application Mode is set to
[2] Position Control.
[190] Safe Function
active
[193] Sleep mode The frequency converter/system has
entered sleep mode. See parameter group
22-4* Sleep Mode.
[194] Broken belt A broken-belt condition has been
detected. See parameter group 22-4*
Sleep Mode.
[239] STO function
fault
5-30 Terminal 27 Digital Output
Option: Function:
[0] * No operation
[1] Control Ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Stand-by / no warning
[5] Running
[6] Running / no warning
[7] Run in range/no warn
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of frequency range
[16] Below frequency, low
[17] Above frequency, high
[18] Out of feedb. range
[19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[22] Ready, no thermal warning
[23] Remote,ready,no TW
[24] Ready, no over-/ under voltage
[25] Reverse
[26] Bus OK
[27] Torque limit & stop
[28] Brake, no brake warning
[29] Brake ready, no fault
[30] Brake fault (IGBT)
[31] Relay 123
[32] Mech brake ctrl
[36] Control word bit 11
5-30 Terminal 27 Digital Output
Option: Function:
[37] Control word bit 12
[40] Out of ref range
[41] Below reference, low
[42] Above ref, high
[43] Extended PID Limit
[45] Bus ctrl.
[46] Bus control, timeout: On
[47] Bus control, timeout: O
[55] Pulse output
[56] Heat sink cleaning warning, high
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
[91] Encoder emulate output A
[160] No alarm
[161] Running reverse
[165] Local ref active
[166] Remote ref active
[167] Start command activ
[168] Drive in hand mode
[169] Drive in auto mode
[170] Homing Completed
[171] Target Position Reached
[172] Position Control Fault
[173] Position Mech Brake
[190] Safe Function active
[193] Sleep Mode
[194] Broken Belt Function
5-34 On Delay, Digital Output
Range: Function:
0.01 s* [0 - 600 s]
5-35 O Delay, Digital Output
Range: Function:
0.01 s* [0 - 600 s]
Parameter Descriptions
VLT
®
Midi Drive FC 280
56 Danfoss A/S © 12/2015 All rights reserved. MG07C102
