3.1.4 PROFINET Cables
PROFINET cables used are based electrically on category 5 balanced LAN cables according to ISO/IEC 11801 Edition 2.0, Class
D.
Type C cables can be used in special applications (for example, the use of trailing cables and frequently moved machine
parts) even though their design and mechanical parameters can deviate from the specifications of type A and type B cables.
Still, most of the electrical parameters (e.g. impedance levels) are retained. Highly flexible copper cables generally have the
finest stranded conductors and, for example, a highly resistant polyurethane outer sheath.
Various outer sheath materials are permitted to meet the various demands regarding resistance of industrial environments
and exterior/underground laying (natural and synthetic oil, grease, coolants/lubricants, chemicals, high and low temper-
atures, UV radiation, etc.).
Cable type Application type A Application type B Application type C
Design Data Cable Data Cable Data Cable
Cable Installation Type Stationary, no movement
after installation
Flexible, occasional movement
or vibration
Special Applications (e.g. highly flexible,
permanent movement, vibration or torsion)
Cable marking PROFINET type A PROFINET type B PROFINET type C
Core Cross Section AWG 22/1 AWG 22/7 AWG 22/..
Outer Diameter 5.5-8.0 mm Application
Core Diameter
1.5 ± 0.1 mm
Application
Colour (Outer Sheath) Green RAL6018 Application
Core Identification (colours) star
quad 2 pair
white, yellow, blue, orange Pair 1: white (RXD+), blue (RXD-) Pair 2: yellow(TXD+), orange(TXT-)
Number of Cores 4
Cable Design 2 pairs or 1 star quad
Shielding Design Type Aluminum Foil + Cu braiding Application
Which Plug for which Cable Type RJ-45 (IP20 or IP65/67)/M12
Table 3.1 All Balanced Cables used shall Comply with these Parameters
Relevant Standard
ISO/IEC 11801 Edition 2.0, IEC 61156 (minimum Category 5)
Delay Skew
<≤20 ns/100 m
Transfer Impedance
<≤50 m Ohm/m at 10 MHz
Table 3.2 Transmission Performance Requirements
How to Install Operating Instructions
10 Danfoss A/S © Rev. 2014-02-27 All rights reserved. MG90U302
