Danfoss VLT PROFINET MCA 120 User Manual

8.5 PROFINET-specific Parameter List
Parameter Default value Range Conver-
sion index
Data type
8-01 Control Site [0] Dig. & ctrl. word [0-2] - Uint8
Parameter 8-02 Control Source [0] FC RS485 [0-4] - Uint8
Parameter 8-03 Control Timeout Time 1 0.1-18000 -1 Uint32
Parameter 8-04 Control Timeout
Function [0] Off [0-10] - Uint8
8-05 End-of-Timeout Function [0] Hold set-up [0-1] - Uint8
Parameter 8-06 Reset Control Timeout [0] Do not reset [0-1] - Uint8
Parameter 8-07 Diagnosis Trigger [0] Disable [0-3] - Uint8
Parameter 8-10 Control Profile
[0] FC profile [0-x] - Uint8
8-13 Configurable Status Word STW
8-50 Coasting Select [3] *Logic OR [0-3] - Uint8
Parameter 8-51 Quick Stop Select [3] *Logic OR [0-3] - Uint8
8-52 DC Brake Select [3] *Logic OR [0-3] - Uint8
8-53 Start Select [3] *Logic OR [0-3] - Uint8
Parameter 8-54 Reversing Select [3] *Logic OR [0-3] - Uint8
8-55 Set-up Select [3] *Logic OR [0-3] - Uint8
8-56 Preset Reference Select [3] *Logic OR [0-3] - Uint8
8-90 Bus Jog 1 Speed 100 rpm
0-4-13 Motor Speed High
Limit [RPM]
67 Uint16
8-91 Bus Jog 2 Speed 200 rpm
0-4-13 Motor Speed High
Limit [RPM]
67 Uint16
9-15 PCD Write Configuration - - - Uint16
9-16 PCD Read Configuration - - - Uint16
Parameter 9-22 Telegram Selection - [0-108] - Uint8
Parameter 9-23 Parameters for Signals - 0-573 - Uint16
Parameter 9-27 Parameter Edit [1] Enabled [0-1] - Uint16
9-28 Process Control [1] Enable cyclic master [0-1] - Uint16
9-44 Fault Message Counter 0 [0-8] 0 Uint16
9-45 Fault Code 0 - - Uint16
9-47 Fault Number 0 - - Uint16
9-52 Fault Situation Counter 0 0-1000 0 Uint16
9-53 Profibus Warning Word 0 16 bits 0 V2
9-64 Device Identification 0 [0-10] 0 Uint16
9-65 Profile Number 0 8 bits 0 Uint8
Parameter 9-70 Programming Set-up [9] Active set-up [0-9] - Uint8
Parameter 9-71 Profibus Save Data
Values [0] Off [0-2] - Uint8
9-72 ProfibusDriveReset [0] No action [0-2] - Uint8
9-80 Defined Parameters (1) - 0-115 0 Uint16
9-81 Defined Parameters (2) 0-115 0 Uint16
9-82 Defined Parameters (3) - 0-115 0 Uint16
9-83 Defined Parameters (4) - 0-115 0 Uint16
9-90 Changed Parameters (1) - 0-115 0 Uint16
9-91 Changed Parameters (2) - 0-115 0 Uint16
9-92 Changed Parameters (3) - 0-115 0 Uint16
9-93 Changed Parameters (4) - 0-115 0 Uint16
12-00 IP Address Assignment 0.0.0.0 0-255 - Unsigned 8
12-01 IP Address 0.0.0.0 0-255 - Oct. string 4
Parameter 12-02 Subnet Mask 0.0.0.0 0-255 - Oct. string 4
12-03 Default Gateway 0.0.0.0 0-255 - Oct. string 4-
Parameters Operating Instructions
54 Danfoss A/S © Rev. 2014-02-27 All rights reserved. MG90U302
