12-94 Broadcast Storm Protection
Range: Function:
The “OFF” means that the filter is disabled - all
broadcast messages passes through. The value
“0%” means that no broadcast messages passes
through. A value of “10%” means that 10% of the
total bandwidth is allowed for broadcast
messages, if the amount of broadcast messages
increases above the 10% threshold, they will be
blocked.
-1
%*
[-1 -
20 %]
12-95 Broadcast Storm Filter
Option: Function:
Applies to parameter 12-94 Broadcast
Storm Protection; if the Broadcast Storm
Protection should also include Multicast
telegrams.
[0] * Broadcast only
[1] Broadcast &
Multicast
12-96 Port Config
Enables/disables port-mirroring function. For troubleshooting
with a network analyzer tool.
Option: Function:
[0] Normal No port-mirroring
[1] Mirror Port 1 to 2 All network traffic on port 1 will
be mirrored to port 2.
[2] Mirror Port 2 to 1 All network traffic on port 2 will
be mirrored to port 1.
[10] Port 1 disabled
[11] Port 2 disabled
[254] Mirror Int. Port to 1
[255] Mirror Int. Port to 2
12-98 Interface Counters
Range: Function:
4000* [0 - 4294967295 ] Read only. Advanced Interface
counters, from built-in switch, can be
used for low-level troubleshooting,
The parameter shows a sum of port
1+port 2.
12-99 Media Counters
Range: Function:
0* [0 - 4294967295 ] Read only. Advanced Interface counters,
from built-in switch, can be used for low-
level troubleshooting, The parameter
shows a sum of port 1+port 2.
Parameters Operating Instructions
MG90U302 Danfoss A/S © Rev. 2014-02-27 All rights reserved. 53
