8-04 Control Timeout Function
Select the time-out function. The time-out function activates
when the control word fails to be updated within the time
period specified in parameter 8-03 Control Timeout Time.
Option: Function:
[7] Select setup 1 Changes the set-up upon reestablishment
of communication following a control
word time-out. If communication resumes
after a time-out, parameter 8-05 End-of-
Timeout Function defines whether to
resume the set-up used before the time-
out, or to retain the set-up endorsed by
the time-out function.
[8] Select setup 2
See [7] Select setup 1
[9] Select setup 3
See [7] Select setup 1
[10] Select setup 4
See [7] Select setup 1
[20] N2 Override
Release
NOTICE
To change the set-up after a time-out, the following
configuration is required:
Set 0-10 Active Set-up to [9] Multi set-up and select the
relevant link in 0-12 This Set-up Linked to.
8-05 End-of-Timeout Function
Option: Function:
Select the action after receiving a valid control
word following a time-out. This parameter is
active only when 8-04 Control Timeout Function
is set to [7] Set-up 1, [8] Set-up 2, [9] Set-up 3 or
[10] Set-up 4.
[0] Hold set-
up
Retains the set-up selected in 8-04 Control
Timeout Function and displays a warning, until
8-06 Reset Control Timeout toggles. Then the
frequency converter resumes its original set-up.
[1] Resume
set-up
Resumes the set-up active before the time-out.
8-06 Reset Control Timeout
This parameter is active only when [0] Hold set-up has been
selected in parameter 8-05 End-of-Timeout Function.
Option: Function:
[0] Do not reset
Retains the set-up specified in
parameter 8-04 Control Timeout Function,
following a control word time-out.
[1] Do reset Returns the frequency converter to the original
set-up following a control word time-out. The
frequency converter performs the reset and
then immediately reverts to the [0] Do not reset
setting
8-07 Diagnosis Trigger
Option: Function:
Enables and controls the drive diagnosis
function.
[0] Disable Extended diagnosis data are not sent even if
they appear in the frequency converter.
[1] Trigger on
alarms
Extended diagnosis data are sent when one or
more alarms appear.
[2] Trigger
alarm/warn.
Extended diagnosis data are sent if one or
more alarms/warnings appear.
8-08 Readout Filtering
If the speed feedback value readouts on fieldbus are fluctuating,
this function is used. Select filtered, if the function is required. A
power-cycle is required for changes to take effect.
Option: Function:
[0] Motor Data Std-
Filt.
Select [0] for normal bus
readouts.
[1] Motor Data LP-
Filter
Select [1] for filtered bus
readouts of the following
parameters:
16-10 Input Power [kW]
16-11 Input Power [hp]
16-12 Motor Voltage
16-14 Motor current
16-16 Torque [Nm]
16-17 Speed [RPM]
16-22 Torque [%]
16-25 Torque [Nm] High
8-10 Control Profile
Select the interpretation of the control and status words
corresponding to the installed fieldbus. Only the selections valid
for the fieldbus installed in slot A will be visible in the LCP
display.
For guidelines in selection of [0] Frequency converter profile and
[1] PROFIdrive profile refer to the design guide of the related
product.
For additional guidelines in the selection of [1] PROFIdrive profile,
[5] ODVA and [7] CANopen DSP 402, see Operating Instructions for
the installed fieldbus.
Option: Function:
[0] FC profile
[1] PROFIdrive profile
[5] ODVA
[7] CANopen DSP 402
8-13 Configurable Status Word STW
Option: Function:
This parameter enables configuration of
bits 12–15 in the status word.
[0] No function
[1] * Profile Default Function corresponds to the profile default
selected in 8-10 Control Profile.
Parameters Operating Instructions
MG90U302 Danfoss A/S © Rev. 2014-02-27 All rights reserved. 43
8 8
