31
975676 • Version 2.8 • 19.01.2011
Technical information
Data
Technical data:
Model -
CDP 35T CDP 45T CDP 65T
Working area, humidity %RF 40-100 40-100 40-100
Working area, temperature °C 10-36 10-36 10-36
Air volume at max. external
pressure
m
3
/h 250 500 750
Power supply V/Hz 1 × 230/50 1 × 230/50 1 × 230/50
Max. power consumption kW 0,72 1,05 1,65
Max. ampere consumption A 2.8 4.3 7.2
Refrigerant - R407C R407C R407C
Quantity of refrigerant kg 0.6 0.95 1.6
Noise level* (1 m away from
unit)
dB(A) 44 46 48
Weight kg 57 68 95
Dimensions, H × L × W mm
680 × 890 × 290 680 × 1200 × 290 680 × 1735 × 290
*)
Measured opposite to the duct openings
