4 About the Printer
Printer Left Side
Configuration Label The label shows the location and date of manufacture, the
printer serial number, and lists the options installed.
Manual Advance Knob The knob moves a card in the track to clear a card jam.
Cable Lock Receptacle The receptacle allows you to insert the security plate before
attaching the optional cable lock.
Printer Connections Printer connections include:
Power receptacle
USB connection
Network connection
Printer Access Cover Lock The lock provides secure access to the printer.
Manual Advance
Knob
Printer
Connections
Printer
Connections
Single Hopper
Optional Multi-Hopper
Cable Lock
Receptacle
Configuration
Label
Printer Access
Cover Lock
To Next Page
