SR200 & SR300 Card Printers and LM200 & LM300 Laminators User’s Guide 57
BendRemedy TempLevel Ifinstalled,displaysthetemperaturesetusingthe
StatusMonitor.
Referto“BendRemedyTab”onpage 44formore
information.
Speed Ifinstalled,displaysthespeedsetusingtheStatus
Monitor.
Referto“BendRemedyTab”onpage 44formore
information.
HeatRoller HRControl
Enable
Disable
IndicateswhetherHRcontrolfortheretransferrolleris
enabledordisabled.Displaysthevaluesetusingthe
PrinterSettingtabontheStatusMonitor.
PowerSaving
OFForupto60minutes
Indicateswhetherpowersavingissetfortheretransfer
roller.DisplaysthevaluesetusingthePrinterSetting
tab
ontheStatusMonitor.
Setting:
Display Counter
 TotalCnt
 HeadCnt
 FreeCnt
 CleaningCnt
 ErrorCnt
Usetheupanddownarrowkeystoselectthecard
countertypetobedisplayedontheLCDpanel:
 TheTotalcounteristhedefaultsetting.Itdisplays
thenumberofcardsprinted.TheTotalcounter
cannotbereset.
 TheHeadcounterdisplaysthenumberofcomplete
dyepanels.TheHeadcountercannotbereset.
However,itautomaticallyresetsitselfwhenthe
printheadisreplaced.
 TheFreecounterdisplaysthenumberofcardsthat
haveprinted.TheFreecountercanberesetbythe
user.
 TheCleaningcounterdisplaysthenumberofcards
thathavebeenprintedsincesincethecleaningcard
waslastused.
 TheErrorcounterdisplaysthenumberofcardsthat
werenotprintedcorrectly.
Mode
Counter
LaminatorStat
SelecttheinformationtodisplayontheLCDpanel.
MenuDisplay Settings Function
