Datacolor 650/600/400 User's Guide Controls and Indicators Panel • 17
Controls and Indicators
Controls and Indicators Panel
On all benchtop models, a status panel is located on the top of the instrument. It identifies
the current instrument settings being used. The indicators on the status panel vary,
depending on the model of you are operating.
Datacolor 600/650
The status panel is the same for the Datacolor 650 and 600. It is shown below:
OPTION DESCRIPTION
420
The 420nm UV cutoff filter is selected. All wavelengths below 420nm are
excluded from the light source in the instrument.
460
The 460nm UV cutoff filter is selected. All wavelengths below 460nm are
excluded from the light source in the instrument.
UV Cal
The UV filter option has been properly/successfully calibrated.
