18 • Powering Up Datacolor 650/600/400 User's Guide
OPTION DESCRIPTION
UV Inc.
No UV filter is selected. All UV wavelengths from the light source are
included.
UV Exc.
The UV Excluded filter is selected. No UV wavelengths from the light source
are included.
Ready
Instrument is ready for use.
Spec Exc.
The specular port is open and all measurements exclude the specular
reflection from the sample.
Spec Inc.
The specular port is closed, and all measurements include the specular
reflection from the sample.
USAV
Ultra Small Area View lens position is selected.
SAV
Small Area View lens position is selected.
MAV
Medium Area View lens position is selected.
LAV
Large Area View lens position is selected.
Datacolor 400
Below is the status panel for a 400:
OPTION DESCRIPTION
Spec Inc.
The specular port is closed, and all measurements include the specular
reflection from the sample.
Ready
Instrument is ready for use.
Spec Exc
The specular port is open and all measurements exclude the specular
reflection from the sample.
Powering Up
NOTE
The power cord supplied with the unit must be used.
Use this simple procedure to start using your instrument:
1. Verify all cable connections. The AC power cord should be plugged into an
outlet. The communications cable (serial or USB) should be attached to the
instrument and host computer.
2. Turn on the computer.
