Datacolor 800 User Manual

Datacolor 800, 850, 500, and 550 Series User’s Guide  41
Appendix
Datacolor 800 Instrument Specifications
Specifications are subject to change without notice.
ITEM DESCRIPTION
Instrument Type
Dual beam integrating sphere with xenon flash lamp.
Measuring Geometry
Diffuse illumination, 8º viewing in conformance with CIE
publication No. 15.2 Colorimetry.
Illumination Source
Pulsed xenon, filtered to approximate D65.
Sphere Diameter
152 mm / 6.0 inches
Specular Port
Automated specular included or specular excluded
Spectral Analyzer
Proprietary SP 2000 analyzer with dual 256-diode array and high-
resolution holographic grating.
Wavelength Range
360 – 700nm
Photometric Range
0 to 200%
Black Trap
High performance
Aperture Configuration
Large Area View. 30mm illuminated/ 26mm viewed
Medium Area View. 20mm illuminated/ 16mm viewed
Small Area View. 9mm illuminated/ 5mm viewed
Ultra-Small Area View. 6.5mm illuminated/ 2.5mm viewed
X-Ultra Small Area View*. 3mm illuminated/ 2.5mm viewed
Input Power
Requirements
Input Voltage: 100-240VAC
Number of Phases: Single
Frequency: 50/60 Hz
Power Rating: 80VA
Operating
Environment
Temperature: 5°C to 40°C
Recommended Temperature: 23°C +/- 2°C
Maximum Relative Humidity: 20%-85% non-condensing
Recommended Relative Humidity: 50% +/-15% non-condensing
Altitude: Up to 2,000 meters
Do not store above 140F (60C)
Indoor Use
Do not crush, short circuit, mutilate, reverse polarity, disassemble,
or dispose. In fire, might cause burns or release toxic materials.
Interface
Serial: RS232
USB: 2.0
Ethernet
LCD
3.5" RGB Color Display Module
Max Resolution 320 x 240
Maximum Pixel Clock 28 MHz

Datacolor 800 Specifications

General

Brand	Datacolor
Model	800
Category	Measuring Instruments
Language	English
