Datacolor 800, 850, 500, and 550 Series User’s Guide 45
Miscellaneous Technical Information
System Requirements for USB Connection
Below are the software and firmware versions required to successfully connect a Datacolor
instrument to a USB port.
Operating Systems
Windows 7 or higher
USB Firmware
2.0 or higher
Ethernet Connection Considerations
The instrument connects to an Ethernet port via a standard Cat 5 cable. Because the
distance from the instrument to the closest available LAN connection point varies per
installation, a cable is not provided. Both the instrument and the associated computer must
be on the same Local Area Network (LAN) and configured to be on the same Subnet (e.g.
255.255.255.0). This is not a point to point connection between the instrument and the
computer.
NOTES
The Instrument relies upon a DHCP Server to obtain an IP address and does not have a Host
Name.
RS-232C Connection (Communication Settings)
Parameter Value
Baud Rate 115200
Data Bits 8
Stop Bits 1
Parity N
RS-232C Connector Pin Assignments
Pin # Purpose Direction
2 Transmit data Out (to host)
3 Receive data In (from host)
7 Signal ground
CAUTION
(1) DO NOT WIRE to pins other than 2, 3, and 7.
(2) For all unused inputs, the default is active high.
