Datakom D-300 MK2 User Manual

D-300 MK2 User Manual Firmware V-6.3
L052D01-EN - 72 -
The program mode is driven with a two level menu system. The top menu consists on program groups
and each group consists on various program parameters.
When program mode is entered, a list of available groups will be displayed. Navigation between different
groups are made with buttons. Selected group is shown in reverse video (blue on white). In order
to enter inside a group, please press button. In order to exit from the group to the main list please
press button.
Navigation inside a group is made also with buttons. A list of available parameters will be
displayed. Selected parameter is shown in reverse video (blue on white). In order display/change the
value of this parameter, please press button. Parameter value may be increased and decreased with
buttons. If these keys are hold pressed, the program value will be increased/decreased by steps of
10. When a program parameter is modified, it is automatically saved in memory. If button is pressed,
next parameter will be displayed. If button is pressed, then the list of parameters in this group will be
displayed.
15.3. NAVIGATING BETWEEN MENUS
Next group
If inside the
group then
exit to main
PGM menu
Previous
group
Enter inside
the group
Return to the
main menu
Next
parameter
inside the
same group
Edit
parameter
value
Previous
parameter
inside the
same group
