DRAGON™ DX31/MX31
2
2 INSTALLATION
CAUTION
Connections should always be made with power OFF!
2.1 DRAGON™ DX31 INTERFACE CABLE CONNECTIONS
The Dragon™ D131 reader incorporates a multi-standard interface, which can be
connected to a Host by plugging the correct interface cable into the connector and
closing the cable cover.
A. Rubber boot
B. Rubber boot clip
C. Cover
D. Strain relief
E. Screw
A
B
D
E
C
