Datalogic DS2100N Quick Reference Guide

DS2100N QUICK GUIDE
13
APPENDIX
READING DIAGRAMS
DS2100N-1200 (Standard Resolution)
CONDITIONS
Optic Version = Linear
Code = Interleaved 2/5 Code 39
PCS = 0.90
Pitch angle = 0°
Skew angle = 15°
Tilt angle = 0°
*Reading Conditions = Standard
*Scan Speed = 500 scans/sec
* Parameter selectable in Genius™
(0,0) corresponds to the scanner
output window
2
1
0
1
5
4
3
2
3
4
5
(in)
120
100
80
60
40
20
0
20
40
60
80
100
120
(mm)
0 1 3210 6
(in)
45 7 89
0 20 40 60 80 100 120 140 160 180 200 220 240 260
(mm)
280
11
300
12
0.20 mm
(8 mils)
≥
0.50 mm
(20 mils)
0.30 mm
(12 mils)
0.35 mm
(14 mils)
DS2100N-2200 (High Resolution)
CONDITIONS
Optic Version = Linear
Code = Interleaved 2/5 Code 39
PCS = 0.90
Pitch angle = 0°
Skew angle = 15°
Tilt angle = 0°
*Reading Conditions = Standard
*Scan Speed = 500 scans/sec
* Parameter selectable in Genius™
(0,0) corresponds to the scanner
output window
1
0
2
1
2
(in)
0 1 5 3
(in)
2
4
0
10
20
30
40
50 60
70 80
90
100
110
120
130
(mm)
60
50
40
30
20
10
0
10
20
30
40
50
60
(mm)
0.15 mm
(6 mils)
0.20 mm
(8 mils)
≥
0.30 mm
(
12 mils
)
