Datalogic DS2100N Quick Reference Guide

DS2100N QUICK GUIDE
15
READING PERFORMANCE
Version Reading Distance Max Code Resolution
mm (mils)
Speed
scans/s
1XX0 40 mm (1.6 in) - 300 mm (11.8 in) on 0.50 mm (20 mils) codes 0.20 (8) 500 to 800
1XX4 50 mm (1.8 in) - 310 mm (11.8 in) on 0.50 mm (20 mils) codes 0.20 (8) 800 to 1000
2XX0 30 mm (1.2 in) - 90 mm (3.5 in) on 0.30 mm (12 mils) codes 0.15 (6) 500 to 800
2XX4 45 mm (1.8 in) - 100 mm (3.9 in) on 0.20 mm (8 mils) codes 0.12 (5) 800 to 1000
TECHNICAL FEATURES
ELECTRICAL FEATURES DS2100-XXX0 DS2100-XXX4
Power Supply 10 to 30 Vdc
Consumption
0.3 to 0.1 A; 3 W 0.5 to 0.17 A; 5 W
Main Serial Interfaces
Baud Rate
Programmable:
RS232, RS485 FD and HD
1200 to 115200
Auxiliary Interface
Baud Rate
RS232
1200 to 115200
ID-NET™ Interface
Baud Rate
RS485 Half Duplex
Up to 1Mbaud
Inputs
Input 1 (External Trigger), Input 2
Voltage
Current Consumption
Minimum Pulse Duration
Optocoupled, polarity insensitive
10 to 30 Vdc
12 mA max.
5 ms
Outputs
Output 1, Output 2
V
CE
Collector Current
V
CE Saturation
Power Dissipation
Optocoupled
30 Vdc max.
40 mA continuous max.; 130 mA pulsed max.
1V max. at 10 mA
80 mW max. at 45 °C (ambient temperature)
OPTICAL FEATURES
Light Source Semiconductor laser diode
Wavelength In the range 630 to 680 nm
Safety Class Class 2 – EN 60825-1; CDRH
READING FEATURES
Scan Rate (software programmable) 500 to 800 scans/sec 800 to 1000 scans/sec
Aperture Angle 50°
Maximum Reading Distance
Maximum Resolution
See reading diagrams
ENVIRONMENTAL FEATURES
Operating Temperature c 0° to +45 °C (+32° to +113 °F)
Storage Temperature -20° to +70 °C (-4° to +158 °F)
Humidity max. 90% non condensing
Vibration Resistance
EN 60068-2-6
14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
2 g @ 70 to 200 Hz; 2 hours on each axis
Bump Resistance
EN 60068-2-29
30 g; 6 ms;
5000 shocks on each axis
Shock Resistance
EN 60068-2-27
30 g; 11 ms;
3 shocks on each axis
Protection Class
EN 60529
IP65
PHYSICAL FEATURES
Dimensions 68 x 84 x 34 mm (2.68 x 3.31 x 1.34 in)
Weight 330 g (11.6 oz)
USER INTERFACE
LED Indicators Ready, Good, Trigger, Com, Status, Power On
Multi-function Key X-PRESS™ button
c If the reader is used in high temperature environments (over 40 °C), use of the Beam Shutter is advised (see the Genius™
configuration program) and/or a thermally conductive support (such as the metal bracket provided).
