Datalogic DS2100N Quick Reference Guide

DS2100N QUICK GUIDE
14
DS2100N-1204 High Performance (Standard Resolution)
CONDITIONS
Optic Version = Linear
Code = Interleaved 2/5 Code 39
PCS = 0.90
Pitch angle = 0°
Skew angle = 15°
Tilt angle = 0°
*Code Resolution:
High - for 0.30 mm (12 mils)
codes and smaller
Standard - for 0.50 mm (20 mils)
codes and greater
*Reading Conditions = Standard
*Scan Speed = 1000 scans/sec
* Parameter selectable in Genius™
(0,0) corresponds to the scanne
r
output window
2
1
0
1
5
4
3
2
3
4
5
(in)
0 1 32 10 6
(in)
45 7 89
0 20 40 60 80 100 120 140 160 180 200 220 240 260
(mm
120
100
80
60
40
20
0
20
40
60
80
100
120
(mm)
280
11
300
12
0.15 mm
(6 mils)
0.20 mm
(8 mils)
0.30 mm
(12 mils)
≥
0.50 mm
(20 mils)
DS2100N-2204 High Performance (High Resolution)
CONDITIONS
Optic Version = Linear
Code = Interleaved 2/5 Code 39
PCS = 0.90
Pitch angle = 0°
Skew angle = 15°
Tilt angle = 0°
*Code Resolution:
High - for 0.15 mm (6 mils) codes
and smaller
Standard - for 0.20 mm (8 mils)
codes
*Reading Conditions = Standard
*Scan Speed = 1000 scans/sec
* Parameter selectable in Genius™
(0,0) corresponds to the scanne
r
output window
1
0
2
1
2
(in)
01 5 3
(in)
24
0
10
20
30
40
50 60
70 80
90
100
110
120
130
(mm)
60
50
40
30
20
10
0
10
20
30
40
50
60
(mm)
0.12 mm
(5 mils)
0.15 mm
(6 mils)
≥
0.20 mm
(
8 mils
)
