Datalogic DS8100A-3002 User Manual

INSTALLATION
3
3.2.1 Mounting DS4800
Using the DS4800 mounting bracket you can quickly and easily obtain standard mounting
positions (i.e. 15° Skew angles) for the reader as shown in the following figures:
Pitch
-45° -15° 0° 15° 45°
Skew
Figure 16 – Positioning with L Shape Mounting Bracket
29
