INTRODUCTION
7
1
1.3 PACKAGE CONTENTS
The Falcon X3+ package contains:
− 1 Falcon X3+ mobile computer
− 1 rechargeable battery pack
− 1 blank keypad overlay
− 1 Falcon X3+ Quick Start Guide
− 1 Wavelink Avalanche Insert
− 1 End User License Agreement (EULA) Sheet
Accessories necessary for the Falcon X3+ connection to the host computer and to
the network are packaged separately: the cradle and/or one or more connection
cables.
Remove all the components from their packaging; check their integrity and compare
them with the packing documents.
Keep the original packaging for use when sending products to the
technical assistance center. Damage caused by improper
packaging is not covered under the warranty.
CAUTION
Rechargeable battery packs are not initially charged. Therefore the
first operation to perform is to charge them. See paragraph 2.1.
NOTE

Datalogic falcon x3+ Specifications

General

Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display number of colors	65536 colors
Flash memory	1 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Processor family	PXA 310
Built-in processor	PXA310
Processor frequency	0.806 GHz
Processor manufacturer	Marvell
GPS (satellite)	No
Operating system installed	Windows Embedded Handheld 6.5
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Rear camera resolution (numeric)	3.1 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Battery capacity	5200 mAh
RFID reader	-
Product color	Black
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128), Intelligent Mail, PLANET, POSTNET, RM4SCC / KIX, U.P.C.
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	168 mm
Width	88 mm
Height	225 mm
Weight	674 g
