Datalogic falcon x3+ User Manual

INTRODUCTION
9
1
4. Insert the microSD card with the written part upward. Lock the card into place by
pushing the cardholder down:
5. Replace battery.
1.4.1 Removing the MicroSD Card
To remove the microSD card, follow the steps above to access the SD area, and
remove it from its slot.
Follow proper ESD precautions to avoid damaging the SD. Proper
ESD precautions include, but are not limited to, working on an ESD
mat and ensuring that the operator is properly grounded.
Do not force the card. If you feel resistance, remove the card, check
the orientation, and reinsert it.
Do not use the microSD card slot for any other accessories.
CAUTION

Datalogic falcon x3+ Specifications

General

Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display number of colors	65536 colors
Flash memory	1 GB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Processor family	PXA 310
Built-in processor	PXA310
Processor frequency	0.806 GHz
Processor manufacturer	Marvell
GPS (satellite)	No
Operating system installed	Windows Embedded Handheld 6.5
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Rear camera resolution (numeric)	3.1 MP
USB 2.0 ports quantity	1
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Battery capacity	5200 mAh
RFID reader	-
Product color	Black
Linear (1D) barcodes supported	GS1-128 (UCC/EAN-128), Intelligent Mail, PLANET, POSTNET, RM4SCC / KIX, U.P.C.
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	168 mm
Width	88 mm
Height	225 mm
Weight	674 g
